Battery parameters

Battery rated capacity

215kWh*5

Battery voltage range

672~864V

Battery pack series and parallel connection

1P*20S*12S

Maximum charge/discharge current

140A

Adaptive battery

LFP

Cell Capacity

280Ah

PV Parameters

Maximum PV input voltage

Battery minimum voltage -50V

PV Input power

500kW

AC-side parameters (Off-grid)

Rated AC voltage

500kW

Rated AC frequency

50/60Hz (±5Hz)

THDU

<3% (Linear Load)

Overload capacity

110%, normal operation; 120%, 1 minute

General parameters

Degree of protection

IP20 (Indoor)

Protective Class

/

Isolation mode

Transformer isolation

Shutdown self-discharge

<100W (Without transformer)

Display

LCD

Relative humidity

0 ~ 95% (no condensation)

Noise

<78dB

Ambient temperature

-25°C to +60°C(derating above 45°C)

Cooling mode

Intelligent air-cooled

Altitude

2000m (> 2000m reduction)

Communication interface

Rs485 / CAN

Dimensions (W*D*H)

1200*1000*2300mm(Energy Storage Converter)

1200*800*2100mm(PV Converter)

12192*2438*2896mm(Container)

Weight (approx.)

~17.5t
